通过
特殊的摩擦块，可同时满足上、下行开门轿厢意外移动及上行超速保护的要求。
Special friction disc, can provide protection for unintended car movement happened when the door opens during the elevator moves upwards or downwards and upgoing overspeed simutaneously.
|
安装接口
Arrangement |
A
|
B
|
C
|
|
RB106B
|
130
|
180
|
18
|
|
RB106B技术参数表
Sheet of Technical Parameter |
|||
|
曳引比
Traction ratio |
1:1/2:1/4:1
|
||
|
额定速度(m/s)
Rated speed(m/s) |
0.25-2.5(1:1)
|
||
|
系统质量(kg)
Load(kg) |
1720-4340(1:1)
|
||
|
额定载重(kg)
Capatity(kg) |
300-1000(1:1)
|
||
|
曳引绳直径d(mm)
Traction rope diameter D(mm) |
Φ10-Φ14
|
||
|
曳引绳最外缘的距离(mm)
Traction ropeoutermost distance(mm) |
≤125
|
||
|
最大倾斜安装角度
The maximum tilt angle |
45度(顺时针方向)
45 degrees(clockwise |
||
